Product Description

TECHNICAL CHARACTERISTICS OF THE DIESEL  MOTOR  1012：

MAXIMUM POWER, L.S. (KW)	12,0 (8,89)
FUEL TYPE	DIESEL
STARTING SYSTEM	MANUAL STARTER
ENGINE COOLING SYSTEM	WATER COOLING
FUEL CONSUMPTION (MAXIMUM), L / H	2,27
DRIVE UNIT	V-BELT TRANSMISSION (3 BELTS), 1-DISC CLUTCH
NUMBER OF TRANSMISSIONS FORWARD / BACK	6/2
WIDTH OF CULTIVATION, MM	1000
DEPTH OF CULTIVATION, MM	190
EQUIPMENT	ADVANCED SPARE PARTS, RUBBER WHEELS 6.00-12
EQUIPPED WEIGHT, KG	269

DESCRIPTION OF THE DIESEL CENTAUR MOTOR UNIT  1012：

GOING IN FOOT WITH TIME AND CARRYING OUT CONSTANT MONITORING OF CONSUMER NEEDS, THE TRADEMARK PRESENTS AN UPDATED MODEL OF DIESEL MOBILE WITH HYDRO-MOTO BLOCK 1010

AMONG THE MOST IMPROVEMENT IMPROVEMENTS - AIR FILTER AND GENERATOR.

COMBINED INERTIA-OIL AIR FILTER WITH FOUR FOUR CLEANING DEGREES - DRY CENTRIFUGAL (AIR INTAKE IS INSTALLED 200 MM ABOVE THAN BEFORE), OPERATING AND OPERATING. THE AIR THROUGH THIS THROUGH THIS AIR FILTER IS CLEANED FROM DUST ON 99.0 - 99.5% AND GOES TO THE ENGINE CYLINDER. THIS TIME INCREASES THE MOTOR RESOURCE OF THE ENGINE AND REDUCES OPERATIONAL COSTS.

THE ELECTRIC AC GENERATOR HAS 6 COILS WITH AN INCREASED NUMBER OF CIRCUITS (INCREASED FROM 20 TO 22 CIRCUITS) IN COMPARISON WITH THE USUAL GENERATOR. ALSO INCREASED THE WIDTH OF A SET OF PERMALLOE PLATES (ELECTROTECHNICAL STEEL) FROM 10 MM TO 13 MM, AND BECAUSE OF REDUCING THE PULLEY DIAMETER INSTALLED ON THE GENERATOR SHAFT, INCREASED. ALL OF THIS GIVEN THE OPPORTUNITY TO INCREASE THE POWER OF THE GENERATOR FROM 90 TO 200 W AND TO ACHIEVE STABLE VOLTAGE FROM 13.0 TO 14.7 V. THIS IS MORE THAN SUFFICIENT FOR A BATTERY CHARGING OF BATTERIES AND QUALITATIVE OPERATION OF A HEAVY DUTY HEAD



FEATURES OF THE MODEL  1012



ENGINE

• INCREASED MOTOR RESOURCE - AT THE ACCOUNT OF APPLICATION OF QUALITY MATERIALS AND USE OF MODERN TECHNOLOGIES OF PRODUCTION OF PARTS.
• 5-STEP AIR FILTER: SEMI-TRANSPARENT CYCLONE, OIL TUB, TWO RETAIL AND ONE PAPER FILTER ELEMENTS - EXTENTLY EXTEND THE PERFORMANCE SERVICE PERIOD.
• THE FUEL FILTER METAL HOUSING IS STRONG, DOES NOT BREAK, AND DOES NOT CRACK.
• “MUSHROOM” OIL PRESSURE SENSOR - ALLOWS TO CARRY OUT VISUAL CONTROL OF OPERATION OF THE LUBRICATION SYSTEM AND TO AVOID ENGINE MALFUNCTION DURING NO OIL PRESSURE.
• POWERFUL ELECTRIC STARTER (FOR MODELS WITH ELECTRIC STARTER) - ALLOWS EASY TO START THE ENGINE AT ANYTHING OF THE YEAR, AND ALSO PROVIDES THE CHARGE OF THE BATTERY BATTERY.
• POWERFUL GENERATOR 150 W, TWO TIMES POWERFUL THAN OTHER BRANDS MOTOR UNITS - PROVIDES BRIGHT LIGHT OF HEADLIGHTS AND OPPORTUNITY TO OPERATE IN DARK DAY.
• HIGH FUEL TANK NECK - EASY TO FILL.
• PROTECTION FROM BURNING ON THE SILENCER - IMPROVES THE SAFETY OF OPERATION AND MAINTENANCE OF THE MOTOR UNIT.
• RADIATOR COVER WITH VALVE - ALLOWS TO PRELIMINARY RELEASE PRESSURE IN THE RADIATOR AND AVOID BURNING BY HOT STEAM.

TRANSMISSION

• THREE TRANSMISSION BELTS (ON ANALOGUES - TWO BELTS) - PERFORMING IS EXCLUDED, REDUCING THE LOAD OF THE BELTS WILL EXTENTLY EXTEND THE BELT OF TRANSMISSION SERVICE.
• ADDITIONAL FRONT FOR CONNECTING THE FRONT SUSPENSION (4-HAND PULLEY) - THE POSSIBILITY OF QUICK CONNECTION OF THE ACTIVE FRONT SUSPENSION OR USE OF THE MOTOR UNIT AS AN ACTUATOR FOR STATIONARY EQUIPMENT.
• LONG AXLE, EXTENDED ADJUSTABLE RUTCH OF 845 MM - INCREASES STABILITY OF THE MOTOR UNIT WHEN WORKING ON SLOPES AND IN TRANSPORT WORKS, ALLOWS TO EXTEND THE RUTE UNDER VARIOUS AGRICULTURE.
• SHIFTING GEARS TO 6 LEVER SITES (DO NOT PRESS) - EASY AND CONVENIENT SHIFTING OF GEARS.
• TWO-DISC CLUTCH - EXCLUDES TUBING, HAS AN INCREASED SERVICE LIFE.

​FRAME

• STRENGTHENED FRAME WITH STIFFNESS RIBS, HEAVY 2 KG - HAS AN INCREASED STRENGTH, REDUCES VIBRATION, ENSURES STABILITY OF WORK OF THE BELT
• CASE AND CASES FROM IRON CASTING - MUCH STRONGER STRONGER AND HEAVY THAN ALUMINUM.
• ATTACHING THE STEERER TO 3 BOLTS - RELIABLE AND STRONGER THAN TWO BOLTS, AS LIKE ANOTHER MOTOR UNITS OF OTHER BRANDS.
• ATTACHING THE ENGINE TO 5 BOLTS - MUCH MUCH MORE RELIABLE THAN ATTACHING TO 2 PINS, PERFECTLY REDUCES THE VIBRATION AND EASY TO ADJUST THE POSITION OF THE ENGINE ON THE FRAME.
• HIGH REMOVABLE COMPARTMENT COVER FOR SPARE PARTS - SIGNIFICANTLY INCREASES USEFUL VOLUME OF THE COMPARTMENT, CONVENIENTLY OPENS.
• FRONT FOOT RIGID, FROM THE ROD 16 MM - ENSURES THE STABILITY OF THE MOTOR UNIT WHEN STOPPING, DOES NOT DEFORM AND DOES NOT DEPTH DEEP INTO SOFT SOIL.
• REINFORCED TRAILING DEVICE - ALLOWS TO INSTALL A WIDE RANGE OF ATTACHED AND TRAILED EQUIPMENT, HAS A LONG SERVICE LIFE.
• STEEL BUSHES ON A TRAILED DEVICE - SIGNIFICANTLY REDUCES WEAR AND INCREASES THE SERVICE LIFE OF A TRAILER DEVICE.

ERGONOMICS

• QUALITY EQUIPPED PAINT - RELIABLE PROTECTION AGAINST CORROSION AND ATTRACTIVE APPEARANCE.
• RELIABLE WELDED SEAMS - ENSURE THE STRENGTH AND INTEGRITY OF THE WHOLE DESIGN.
• VOLTAMMETER (ON MODELS WITH ELECTRIC STARTER) - ALLOWS OPERATINGLY CHECK THE CHARGING OF THE BATTERY AND THE OPERATION OF ELECTRICAL EQUIPMENT.
• SPRINGS ON THE STEERING LEVER LEVELS - EXCLUDE VIBRATION AND OPENING OF CONNECTIONS DURING OPERATION.
• THE WHOLE (NOT WELDED) CLUTCH LEVER - DOES NOT BROKEN AND DO NOT DEFORM WHEN ACTIVE USE AS A WELDED LEVER.
